ACCUSTIC ARTS® AMP VI – Our statement in terms of audiophile power amplifiers

for the Chinese market

AMP VI highlights

  • In response to numerous customer requests for more power, we have once again increased the output power of our reference power amplifier
  • Dual-mono reference power amplifier with completely isolated power supply for each amplifier channel
  • 40 selected MOS-FET output transistors of highest quality
  • 2 magnetically shielded and encapsulated toroidal core transformer of premium quality for highest output reserves
  • Gold-plated contact surfaces (components) improve the contact resistance of the AMP VI
  • Optimum smoothing thanks to more than 220,000 µF power supply capacity; premium quality capacitors (“Made in Germany”)
  • Very high damping factor for perfect speaker control
  • ACCUSTIC ARTS® damping factor linearization (switchable)
  • Professional protective circuit against clipping, HF oscillations and too high DC offset
  • Integrated switch-on current limitation for highest operational safety
  • Balanced Input (XLR) and unbalanced input (RCA) – the inputs are switchable
  • All used components and parts are selected and of highest quality
  • Very high quality, gold-plated bi-wiring/bi-amping speaker terminal
  • Extremely stable and resonance optimized, massive aluminium housing; inlay made of massive, high gloss polished and chromed brass
  • ACCUSTIC ARTS® AMP VI is “Handmade in Germany”

Specifications

Voltage gain:
30.0 dB

Power consumption without load:
approx. 240 watts

Power supply capacity:
approx. 220,000 µF

Input resistance:
balanced (XLR): 2 x 16 kΩ
unbalanced (RCA): 15 kΩ

Rated power output (THD+N = 0,1%):
> 2 x 1,600 watts on 2 Ω
> 2 x 1,500 watts on 4 Ω
> 2 x 950 watts on 8 Ω

Frequency response:
10Hz – 50 kHz +0/-0.5 dB
(at 10 watts on 4 Ω)

Damping factor:
> 500 at 1 kHz 10 W on 4 Ω

Signal to noise ratio:
-96 dBA (ref. 6.325 V)

Crosstalk:
105 dB with 1 kHz

Min. loudspeaker impedance:
2 Ω

Distortion (THD+N):
0.003 % on 4 Ω load at 1 kHz and 10 watts

Dimensions (H x W x D)
328 x 530 x 545 mm / 12.9 x 20.9 x 21.5 inches

Weight:
approx. 82 kg / 180.4 lbs
+ 22 kg / 48.5 lbs flight case
